Material Certifications: Which Type Proves What

EN 10204 is a short European standard that names and defines the documents a metal producer can issue with a shipment. That is the whole scope. It does not set a chemistry, it does not set a mechanical property, and it does not say the material is good.

The grade specification does that work. ASTM A276 tells you what 316 bar has to be. EN 10204 only tells you what kind of paper came with it, and specifically whether the numbers on that paper were measured on your material or on some other material made to the same recipe.

That distinction is the reason the standard exists, and it is the only thing you need to hold on to. Everything else is filing detail.

The 2004 revision reduced the list to four. Read the table by the middle column first: whether the test results describe the material you received is the question that separates a useful certificate from a polite letter.

Non specific inspection means the producer tested material made by the same process to the same specification, but not necessarily the material in your box. A mill running thousands of tons of 304 bar can honestly issue a 2.2 covering all of it from a representative sample.

Specific inspection means the producer tested the heat, cast or lot your material came from, and the document carries the identifiers that let you prove the connection. A 3.1 without a heat number is a 3.1 that cannot do its job, which is why the heat number is the field an auditor looks at first.

If you cannot trace the certificate to the bar, the certificate is decorative. That is the failure mode worth designing against, and it usually happens somewhere downstream of the mill rather than at it.

A 3.1 is the document most people mean when they say mill cert or MTR. It carries the producer, the standard and grade, the heat or cast number, the product form and size, the chemical analysis element by element, the mechanical test results, any supplementary tests the order called for, and the signature of an inspection representative who does not report to production.

That last condition is easy to skip past and it is the substance of the type. The independence requirement is what separates a 3.1 from a 2.2 signed by someone senior.

One practical consequence: your machine shop does not issue the 3.1. The producer does. What the shop can do is pass the original through with the parts and, where the job requires it, add its own certificate of conformance saying which heat went into which lot of parts.

A 3.2 adds a second validation from outside the producer. In practice that is the purchaser inspection representative, a third party inspection body engaged by the purchaser, or an inspector named in the regulations governing the product.

It shows up where a regulator or a code is driving the requirement rather than a purchasing preference. Pressure equipment under PED, some offshore and marine classification work, and certain nuclear and defense supply chains all reach for it. In those cases nobody has to be persuaded, because the code names the document.

Outside that, 3.2 costs money and time for a signature. The third party has to be engaged, the inspection has to be witnessed or the records reviewed, and the material usually cannot ship until that happens. Asking for a 3.2 because it sounds more rigorous than a 3.1 is a common and expensive habit.

The 1991 edition split type 3.1 into 3.1.A, 3.1.B and 3.1.C, and had a separate 2.3. Those designations were retired in the 2004 revision, but they survive in old drawings, old quality manuals and the vocabulary of people who learned the standard before 2004.

The useful translation is that 3.1.B, by far the most commonly quoted of them, maps to today's 3.1. If a drawing calls for 3.1.B, supply a 3.1 and note the equivalence rather than arguing about it.

North American practice uses its own vocabulary for overlapping ideas. A mill test report or MTR is functionally the 3.1 case. A certificate of conformance, or CoC, is a statement of compliance closer in spirit to a 2.1, and it is often issued by a distributor or a shop rather than by the mill.

The certificate itself is cheap. The traceability discipline behind it is not.

Stock bought from a service center with certs on file usually carries a 3.1 at no visible premium, because the material was already segregated and documented. Stock bought as commodity cutoffs, remnant or unsegregated inventory often cannot be certified at all, and the honest answer from the shop is that the price you were quoted assumed the cheaper material.

So a certification requirement introduced late reprices the job twice: once for material that has to be bought from a certified source in a certified size, and once for the lot control that keeps your parts separable from everyone else's through the shop. Neither is expensive on its own. Both are annoying to add after the quote.

Put the requirement on the drawing or in the purchase order text, not in an email during the job. Name the type number explicitly: "Material certification per EN 10204 type 3.1 required" leaves nothing to interpret.

Say what has to be traceable. Material certification to the heat is the usual bar. If you also need the finished parts tied back to that heat, say so, because that is a lot control requirement on the shop rather than a document requirement on the mill.

Ask for the certificate to be supplied with the shipment rather than on request. Certificates that live on a supplier server are the ones that go missing during an audit two years later.

Then ask the one question that catches most problems early. Is this size and grade available from stock that carries a 3.1, and if not, what is the lead time for material that does?
