Get quotes for custom laser cut parts
Flat parts cut from sheet metal on fiber lasers, fast and accurate with a narrow kerf and a clean edge. Ideal for thin-to-medium gauge and high part counts, and the first step before bending. Upload your DXF and we'll source competitive quotes from qualified manufacturing partners.
STEP · STL · IGES · DWG · DXF · PDF · and more
Uploads are secure & confidential
Processes
Laser Cutting processes
Compare the specific processes and pick the right one for your part.
How OpenSpindle works
We tap our partner network. You get the best-match quote.
Upload your part and we tap our network of partner shops to get you a competitive, all-in quote that is the best match for the job.
One upload
A CAD file or a sketch. That is the whole ask on your end.
Your best-match quote
Sourced from the partner shops set up for your exact part.
All-in, on your timeline
Machining, finishing, and shipping detailed to your turnaround.
Sheet stock our laser shops cut
Laser cutting runs flat sheet and plate. Common metals are below; reflective alloys want a fiber laser. If yours is not here, ask when you request a quote.
Specs
Tolerances you can expect
| Feature | With a drawing | No drawing supplied |
|---|---|---|
| Cut edge position | ±0.003 in | ISO 2768 Medium |
| Hole diameter | ±0.005 in | ISO 2768 Medium |
| Kerf width | ~0.006-0.015 in | Set by thickness and power |
| Edge quality | 32-125 Ra | As-cut, light discoloration |
Fiber lasers hold ±0.003 to ±0.005 in on thin-to-medium gauge with a narrow kerf and a small heat-affected zone. Tolerances open up as thickness climbs; call out the critical edge and shops confirm before cutting.
Design rules
How to design for Laser Cutting
Most laser design rules scale with material thickness. These keep features clean and fully cut.
| Design rule | Typical spec | Why |
|---|---|---|
| Min hole diameter | >= material thickness | Smaller holes taper and may not fully pierce. |
| Min slot width | >= material thickness | Narrow slots close up on thicker stock. |
| Min web / feature | >= material thickness | Thin webs between features overheat and burn away. |
| Min hole-to-edge | >= 1x thickness | Features too close to an edge distort from heat. |
| Max thickness (typical) | ~1 in steel, less on aluminum/stainless | Reflective and thick metals need higher power. |
| Kerf | ~0.006 to 0.015 in | Account for the cut width on tightly mating parts. |
Typical starting points; a shop confirms against your material and thickness.
Secondary operations
Inserts, hardware and finishing
Threads and inserts
Holes are cut in place; hardware like PEM inserts, standoffs, and nuts is pressed after cutting. Countersinks and taps are done as a secondary op.
Finishing
Applied after cutting and any bending. As-cut ships fastest; deburring, graining, and coatings are common on laser-cut metal.
| Finish | Materials | Adds | Can be applied with |
|---|---|---|---|
| As-cut | All | +0 days | Anything |
| Deburr / edge break | All metals | +1 day | Graining |
| Powder coat | Steel, aluminum | +3-5 days | After bending |
| Anodize | Aluminum, titanium | +3-5 days | Deburr first |
Laser edges carry a thin oxide or discoloration. If the part shows or gets coated, ask for a deburr and a clean edge so the finish takes evenly.
Process comparison
Laser cutting vs other processes
When another cutting process fits better than a laser.
| Process | Best for | Typical volume | Choose it over Laser Cutting when |
|---|---|---|---|
| Waterjet Cutting | Thick, heat-sensitive, or reflective materials | Prototype to production | Heat would distort the part, or the material is thick or reflective. |
| Plasma Cutting | Thick steel plate at lower cost | Prototype to production | You need thick steel cut fast and cost matters more than edge quality. |
| CNC Routing | Wood, plastics, composites | Prototype to production | The material is a non-metal better cut with a router. |
Get a better quote
Getting a quote that comes back fast
| Instead of | Send this |
|---|---|
| "Cut this bracket from sheet" | "5052-H32 aluminum, 0.100 in, flat pattern per DXF, qty 200" |
| "Some holes for mounting" | "4x ⌀0.20 in holes, ±0.005 on the bolt pattern per drawing" |
| "It gets bent after" | "3 bends, flat pattern supplied, or bend per the STEP model" |
Send a flat DXF for the cut and note any bends. If the part is formed, say so up front so the shop nests the flat pattern, not the finished part.
Applications
Industries we serve
Laser cutting shops on OpenSpindle produce brackets, panels, enclosures, and gaskets for demanding industries, including AS9100 and ISO 9001 shops.
More on OpenSpindle
Need a different process?
Get a quote for these capabilities too.
Designing for this process
What actually changes your quote
Not a definition of laser cutting. The design choices that move your price and lead time.
Thickness sets everything
Speed, kerf, and edge quality all track sheet thickness. Thin-to-medium gauge cuts fast and clean; every step thicker slows the cut and opens tolerances. Spec the thinnest gauge that carries the load.
Tiny holes cost more
A hole smaller than the material thickness is slow and can char the edge. Keep hole diameters at or above the sheet thickness where you can, or expect a drilled secondary op.
Nest for the sheet
Parts that pack tightly into a standard sheet waste less material. Odd shapes and oversized parts leave scrap you pay for. Simple outlines and shared edges cut cost on volume.
Reflective metals want fiber
Copper, brass, and aluminum reflect the beam. Fiber lasers handle them, older CO2 machines may not. Naming the alloy up front routes your part to a shop with the right laser.
Questions
Frequently asked questions
Fiber lasers are the modern standard for metal and cut reflective alloys like copper, brass, and aluminum that used to give CO2 lasers trouble. CO2 lasers are still used for non-metals like acrylic, wood, and some plastics. Tell the shop your material and they route it to the right machine.
