TIG vs MIG Welding

TIG, properly gas tungsten arc welding, strikes an arc between a tungsten electrode and the part. The electrode is not consumed. If the joint needs filler, the welder feeds a rod into the puddle with the other hand while modulating current with a foot pedal or torch control. Two hands and a foot, all working the same puddle.

MIG, properly gas metal arc welding, runs a spool of wire through the torch and into the arc. The wire is both electrode and filler, fed continuously at a set rate. The welder controls travel speed and gun angle; the machine controls deposition. One hand, one trigger.

That difference in mechanism is the whole article. Everything below follows from a hand-fed puddle you can throttle versus a continuously fed one you cannot.

Below about 18 gauge, MIG becomes difficult. The wire feed delivers heat faster than thin sheet can shed it, and the result is burn-through, blown-out edges and warped panels. TIG lets the welder back the current off mid-bead and keep the puddle small, which is why thin stainless boxes, small brackets and tube frames in light wall are almost always TIG.

Above roughly a quarter inch, the argument inverts. Filling a groove in half-inch plate with hand-fed TIG is possible and slow, and slow is the cost. MIG fills it in fewer passes with less labor, and on structural steel nobody is looking at the bead anyway.

Between those two, thickness stops deciding and the other factors take over: what the metal is, whether the weld is visible, and how many you need.

Steel is the easy case. Carbon steel welds well either way, and the choice comes down to thickness, cosmetics and volume.

Stainless is where heat control starts to matter for reasons beyond distortion. Too much heat, and chromium carbides precipitate at the grain boundaries in the heat-affected zone, which strips the local chromium that gives stainless its corrosion resistance. The zone next to a hot weld can then rust while the rest of the part does not. TIG's lower and more controllable heat input reduces that exposure, and it is one reason stainless assemblies for food, medical or marine service are usually specified TIG.

Aluminum is the sharpest split. It conducts heat away fast, oxidizes instantly, and the oxide melts far hotter than the metal underneath. TIG on AC breaks up that oxide layer during the weld and gives the control aluminum's narrow window needs. MIG can weld aluminum, but the soft wire needs a spool gun or a push-pull feeder to avoid birdnesting in the liner, and the process gives up much of the control that made TIG the default. If your part is aluminum and the weld matters, expect it to be quoted TIG.

A TIG bead is usually presentable as welded. The stacked-dime appearance people associate with good TIG is the visible record of a hand-fed puddle, and on a visible corner it can be left alone.

A MIG bead is rarely left alone on a cosmetic part. It is coarser, it carries spatter, and if the part will be seen it gets ground flush and blended, which is labor. That labor is the trap in comparing the two on speed. MIG lays the weld down faster, then a person spends time removing the evidence. On a part where every joint is visible, the finishing hours can erase the deposition advantage entirely.

So the real question is not which process welds faster. It is which process gets you to a finished, acceptable part in fewer total hours. On a hidden structural weldment that is usually MIG. On a visible stainless enclosure it is usually TIG, even though the arc time is longer.

At prototype and low volume, TIG's labor cost is spread across few parts and its flexibility is worth paying for. Fixturing is minimal, changes are easy, and a skilled welder can work from a drawing without dedicated tooling.

As volume rises, MIG's speed compounds and the fixturing investment starts to pay back. Once a weldment is repeating in the hundreds, shops will look at MIG, at fixtures that hold the distortion out, and at whether the joints can be redesigned so a faster process can reach them.

There is a third option worth knowing about at that point. Robotic MIG is common on repeating weldments, and it changes the economics again: consistent travel speed, consistent heat, and much less bead variation than a person can hold over a shift. It needs volume to justify programming and fixturing, but if your part is heading for production it is worth asking whether it should be designed for it now rather than re-engineered later.

Specifying the process by name is usually the wrong instinct. Shops know which process suits the joint, and pinning them to one can price you out of a perfectly good alternative. What you should specify is the requirement the weld has to meet, and let the shop choose the process that meets it.

Say whether the weld is structural or cosmetic, and where. Say whether it must be continuous or whether stitch welds are acceptable, because continuous welding on thin sheet is an invitation to distortion and is often unnecessary. Give the weld symbol with size, and say which side. If the assembly has to hold a dimension after welding, say so and give the tolerance, because that is what tells the shop to fixture it, to sequence the welds, or to plan a straightening operation.

If the part is stainless and will live outdoors or in a wash-down environment, say that too. It tells the shop to control heat input and to passivate afterward, and it is the difference between a part that stays bright and one that shows rust at every joint in six months.
